First off, the original Atari 2600 - the 1977-1978 "Heavy Sixer" variety have a very decorative back panel where the joystick ports are located, and these ports are inset and surrounded by very nice looking molded plastic trim in the back of the console. The unfortunate side effect of this is depending on which DB-9 joystick connectors your "Heavy Sixer" 2600 came with, you might just barely get the Wireless Dongles to fit just enough to work, or like me, you might end up with just the +5v and gnd lines being the only visibly working parts on your console at best...if they even fit at all.

The second problem that plagues BOTH consoles, is that the "Sixer" (six switch models) models of the Atari 2600 have a CD4050 Hex Buffer chip inline with the joystick ports used for "debouncing" the fire button, as well as some additional purposes that contribute to these models hightly desirable video output because of the high, very sweet video saturation. The Woody, Vader, and Junior consoles, all don't have this problem due to changes in the circuitry in 1980. This hex buffer is a catalyst to the "music" or "noise" people get when the dongles are plugged in and working. YOu get this long sawtooth wave of noise that changes in pitch seemingly at random, and even causes some video interference.

The problem seems to stem from a constant 5vdc pushed down the joystick lines causing the noise...my anti-braniac theory upon hearing someone with a scope or some other advanced Electronics Engineer equipment was that this was definatley a part of the cause.

One of the first fixes was to remove the 5 volts from the ATari itself and run a regulated voltage to the dongle. While this indeed fixed the problem (makes sense, now the dongle is no longer powered by the Atari with it's noisy power) - the obvious issue is an external power source, which somewhat defeats the purpose of wireless controllers because now you're just exchanging the controller wire with another wire to power the dongle.

Another fix I saw was cutting a trace on the motherboard (the main circuit board inside the aluminum box in the middle of the Atari where the Cartridge port is). The trace goes down the left side of the board (Facing the bottom, cartridge port toward the top), and has to be cut and then re-routed, but it seems this means altering the original board of a expensive late 70's Atari, and it also means if your wire placement isn't good you'll get some video interference.
